13 Summary of Confi guration parameters
Date: Model ATR236:
Installer: System:
Notes:
Command output type selection
Analog input confi guration
Number of decimal points
Lower limit setpoint
Upper limit setpoint
Offset calibration
Gain calibration
Regulation type
Command output reset type
Contact state for command output in case of error
Defi ne the OUT1 led state
Hysteresis in ON / OFF or dead band in P.I.D.
Command delay
Command setpoint protection
Proportional band
Integral time
Derivative time
Cycle time
Higher limit output percentage
Alarm 1 selection
Alarm 1 output contact and intervention type
Reset type of alarm 1 contact
State of contact for alarm 1 output
State of OUT2 led
Alarm 1 hysteresis
Alarm 1 delay
Alarm 1 set protection
Analog converter fi lter
Sampling frequency of analog converter
Display fi lter
Autotuning type selection
