119
MAINTENANCE
Gearcase Oil
Gearcase Oil Change
The drain plug is located on the bottom
of the gearcase.
NOTE: Polaris does not recommend tip-
ping the snowmobile onto it's side
for service. Any time the snowmo-
bile is tipped onto it's left side,
always check the oil level and
clean the foam oil breather ele-
ment. See page 114.
1. Position the vehicle on a level sur-
face.
2. Remove the drain plug and drain the
oil into a drain pan. Allow the oil to
drain completely
NOTE: The sealing surfaces on the drain
plug and the gearcase should be
clean and free of burrs, nicks or
scratches.
3. Reinstall the drain plug. Torque to 6-10 ft. lbs. (8-13 Nm).
4. Remove the dipstick.
5. Add 9 oz. (266 ml) of the recommended oil. Do not overfill.
6. Reinstall the dipstick, making sure it is seated properly.
Drain Plug
