54
THE PERFECT FIT
IQ Front Suspension Adjustments
Independent Front Suspension (IFS)
Break in the suspension for approximately 150 miles (240 km) before
making any fine-tuning adjustments.
Settings will vary from rider to rider, depending on rider weight, vehicle
speed, riding style, and trail conditions. We recommend starting with
factory settings and then customizing each adjustment individually to
suit rider preference. The snowmobile should be methodically tested,
one change at a time, under the same conditions (trail and snow condi-
tions, vehicle speed, riding position, etc.) after each adjustment until the
best ride is achieved.
IFS Components
1. Skis
2. Front shocks and springs
3. Rod ends
4. A-arms
IFS Adjustment Options
• Shock damping (if equipped
with ArvinMeritor MPV
Select shocks)
• Front shock spring preload
• Optional springs
• Optional shock valving
(SwitchBack)
• Toe (ski alignment) (see page 146)
• Camber (see your dealer)
1
2
3
4
