72
THE PERFECT FIT
Handlebar Adjustments
Use the RIDER SELECT feature to adjust handlebar position. See page
34. Use the following steps to adjust handlebar angle at the handlebar
block.
1. Remove the handlebar cover
to expose the handlebar and
the four adjuster block bolts.
NOTE: If equipped, remove the
mountain bar.
2. Using a 7/16" wrench, loosen
the four nuts on the bottom of
the adjuster block (turn han-
dlebar to left or right for
access to back nuts).
NOTE: If necessary, pry the blocks
apart with a screwdriver.
3. Adjust the handlebar to the
desired height. Be sure han-
dlebars, brake lever and throt-
tle lever operate smoothly and
do not hit the gas tank, wind-
shield or any other part of the
machine when turned fully to
the left or right.
4. Torque the front bolts first,
then torque the rear bolts.
Torque the bolts to 11-13 ft.
lbs. (15-18 Nm).
5. Reinstall the handlebar cover.
Mountain Bar
Handlebar
Cover
Adjuster
Block
Bolts
Nuts
