THREAD
SIZE DRILL SIZE
THREAD
SIZE DRILL SIZE
#3–48 5/64 5/8–18 37/64
#3–56
45
3/4–10 21/32
#4–40 43 3/4–16 11/16
#4–48 42 7/8–9 49/64
#5–40
38
7/8–14 13/16
#5–44
37 1–8
7/8
#6–32
36 1–12
59/64
#6–40
33
1 1/8–7 63/64
#8–32
29
1 1/8–12 1 3/64
#8–36 29 1 1/4–7 1 7/64
#10–24 24 1 1/4–12 1 11/64
#10–32
21
1 1/2–6 1 11/32
#12–24
17
1 1/2–12 1 27/64
#12–28
4.6 mm
1 3/4–5 1 9/16
1/4–20
7
1 3/4–12 1 43/64
1/4–28
3
2–4 1/2 1 25/32
5/16–18
F 2–12 1 59/64
5/16–24
I
2 1/4–4 1/2 2 1/32
3/8–16 O 2 1/2–4 2 1/4
3/8–24 Q 2 3/4–4 2 1/2
7/16–14
U 3–4
2 3/4
7/16–20 25/64
METRIC TAP / DRILL SIZES
TAP SIZE DRILL SIZE DECIMAL
NEAREST
FRACTION
3 x .50
#39
0.0995
3/32
3 x .60
3/32
0.0937
3/32
4 x .70
#30
0.1285
1/8
4 x .75
1/8 0.125 1/8
5 x .80 #19 0.166 11/64
5 x .90
#20
0.161
5/32
6 x 1.00
#9
0.196
13/64
7 x 1.00
16/64
0.234
15/64
8 x 1.00 J 0.277
9/32
8 x 1.25
17/64
0.265
17/64
9 x 1.00 5/16 0.3125 5/16
9 x 1.25
5/16
0.3125
5/16
10 x 1.25
11/32
0.3437
11/32
10 x 1.50 R 0.339
11/32
11 x 1.50
3/8
0.375
3/8
12 x 1.50
13/32
0.406
13/32
12 x 1.75 13/32 0.406 13/32
DECIMAL EQUIVALENTS
FRACTION DECIMAL MM TO INCHES
1/64 0.0156″
1/32
0.0312″ 1 mm = 0.0394″
3/64
0.0469″
1/16 0.0625″
5/64
0.0781″ 2 mm = 0.0787″
3/32
0.0938″
7/64 0.1094″ 3 mm = 0.1181″
1/8
0.1250″
9/64
0.1406″
5/32 0.1563″ 4 mm = 0.1575″
11/64
0.1719″
3/16
0.1875″ 5 mm = 0.1969″
FRACTION DECIMAL MM TO INCHES
13/64 0.2031″
7/32
0.2188″
15/64
0.2344″ 6 mm = 0.2362″
1/4 0.25″
17/64
0.2656″ 7 mm = 0.2756″
9/32
0.2813″
19/64 0.2969″
5/16
0.3125″ 8 mm = 0.3150″
21/64
0.3281″
11/32 0.3438″ 9 mm = 0.3543″
23/64
0.3594″
3/8
0.375″
