Installation in a sliding sash window of 378.4“ (950 mm) to 56.7“ (1440 mm) inner width
inclusive
1. Attach the extension panel (c) to the
adjustment panel with the screws (d).
2. Open the window sash and place the
window panel (b) on the window frame.
Slide the adjustment (a) and extension
panels (c) to fit the window frame height.
Secure the window panel to the window
frame with 4 screws.
3. Cut the sponge B to a proper length and
attach it to the window sash.
4. Close the window securely against the
window panel.
5. Cut the sponge A to a proper length and seal
the gap between left side of inner window
sash and outer window sash.
6. Fix the inner window with window
bracket and screw, so that it can not slide
horizontally.
7. Plastic window frame.
8. Wooden window frame.
1.
c
a
b
3.
5.
7.
B
6.
4.
8.
2.
