Prolitec GENIE User Manual

Genie 11Chapter 4 Installation
Step 7 – Final Two Screws
Secure the appliance to the wall with the nal two screws.
Step 8 – Replacing the Cover
After cartridge installation and unit programming, replace the cover and lock it, storing the key in a
known location.
4

Prolitec GENIE Specifications

Power

input voltage	100 – 240VAC
input current	0.6A max
output voltage	15VDC
output current	1.2 A
battery type	Lithium 3V, #CR2032

Operating Environment

working temperature	0˚ to 40˚ C
working humidity	85% or less

Capacity

liquid capacity	500 mL cartridges
service area	Up to 15, 000 cu. ft. (425 m[3])

Weight and Dimensions

dimensions	11” x 7.5” x 3” (27.9 cm x 19.1 cm x 7.6 cm)
weight	5.2 lbs (2.4 kg)
