Genie 9Chapter 4 Installation
Step 2 – Mounting Kit, Parts and Tools
The mounting kit provided with Genie includes an installation template and 4 long round-head
screws and 4 wall anchors suitable for plastered drywall. If you have another surface you will need to
get anchors suitable for the wall material and screws that work with these anchors. The screws need
to be the same length as the ones provided.
You will need the following tools:
1. A good level to help you make the installation template
exactly horizontal.
2. A hammer.
3. A Phillips screwdriver to match the screws provided
or whatever screwdriver matches the screws needed
to attach to the anchors you have chosen.
4. A pointed tool like a small screwdriver to insert through
the holes on the appliance to mark the right spot for
the anchors.
5. A Drill.
Step 3 – Positioning the Installation Template
Place the installation template directly over the power outlet (if hardwired or plugged elsewhere,
position the template to the side of the power source). Use the level to make sure the installation
template is horizontal. Position the template so that the electrical outlet is centered in the template.
While holding the bracket level, use a pointed tool, screw or screwdriver to mark the location of the
four wall anchors. Check again with the level to ensure the template is horizontal.
4

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Prolitec GENIE and is the answer not in the manual?

Prolitec GENIE Specifications

Power IconPower
input voltage100 – 240VAC
input current0.6A max
output voltage15VDC
output current1.2 A
battery typeLithium 3V, #CR2032
Operating Environment IconOperating Environment
working temperature0˚ to 40˚ C
working humidity85% or less
Capacity IconCapacity
liquid capacity500 mL cartridges
service areaUp to 15, 000 cu. ft. (425 m[3])
Weight and Dimensions IconWeight and Dimensions
dimensions11” x 7.5” x 3” (27.9 cm x 19.1 cm x 7.6 cm)
weight5.2 lbs (2.4 kg)
