Estimating Cartridge Life
Estimating how long a cartridge will last and the number of days between services is critical to
performing an installation that can be serviced efciently. This includes determining the number of
Genies needed for a space. Please refer to AirQ’s ‘S3 (Sizing, Service & Success) Tool,’ available at
AirQ Tools. The chart below can be used as a rough guideline for sizing.
Room-Size Table
Normal Off-Cycle
(NOC)
Short Off-Cycle
(SOC)
Very Short Off-Cycle
(VSOC)
Output
Level
Range
Room Volume Range Room Volume Range Room Volume Range
CFT CM CFT CM CFT CM
1-5 200-800 6-23 600-2500 17-71 2100-6700 59-190
6-10 1000-1700 28-48 3000-4700 85-133 7500-9700 212-275
11-15 1900-2800 54-79 5100-6600 144-187 10100-11400 286-323
16-20 3000-4000 85-113 7000-8400 198-238 11700-12500 331-354
21-25 4200-5300 119-150 8700-9900 246-280 12700-13300 359-376
26-30 5600-6900 158-195 10200-11200 289-317 13400-13800 379-391
31-35 7200-8600 204-243 11400-12400 323-351 13900-14200 393-402
36-40 8900-10500 252-297 12600-13400 357-379 14300-14600 405-413
41-45 10900-12600 308-357 13500-14200 382-402 14600-14800 413-419
46-50 13100-15000 371-425 14400-15000 408-425 14800-15000 419-425
These settings are suggested as a starting point. Start on the lower end of the range and adjust after
one hour. Fragrance type, room size, number of fresh air changes per hour, temperature, humidity
and user preference will determine the nal setting. Best practice is to use AirQ’s ‘S3 Tool’ at AirQ
Tools.
4

Prolitec GENIE Specifications

Power

input voltage	100 – 240VAC
input current	0.6A max
output voltage	15VDC
output current	1.2 A
battery type	Lithium 3V, #CR2032

Operating Environment

working temperature	0˚ to 40˚ C
working humidity	85% or less

Capacity

liquid capacity	500 mL cartridges
service area	Up to 15, 000 cu. ft. (425 m[3])

Weight and Dimensions

dimensions	11” x 7.5” x 3” (27.9 cm x 19.1 cm x 7.6 cm)
weight	5.2 lbs (2.4 kg)
