Prolitec GENIE User Manual

Genie 6Chapter 4 Installation
Installation
General
Location
Genie is designed for permanent installation on wall surfaces over a 110 to 240V outlet, or used as a
table- or shelf-top unit.
Service Area
The service area range of Genie is from 100 to 15,000 cubic (6 to 425 cubic meters). Of course this
can vary signicantly depending on airow, number of fresh air changes per hour, temperature,
humidity and desired service interval. Genie can be adjusted from 1 to 50 to accommodate these
variations.
Conguration
Genie is available in a wall-mount conguration, which has a 110-240V power source and plug in the
back of the appliance, and must be placed over the power source. Special power supply adapters and
plugs are provided.
Colors
Genie comes standard in black or white, and at sufcient quantities can be special ordered in any
color.
4

Prolitec GENIE Specifications

Power

input voltage	100 – 240VAC
input current	0.6A max
output voltage	15VDC
output current	1.2 A
battery type	Lithium 3V, #CR2032

Operating Environment

working temperature	0˚ to 40˚ C
working humidity	85% or less

Capacity

liquid capacity	500 mL cartridges
service area	Up to 15, 000 cu. ft. (425 m[3])

Weight and Dimensions

dimensions	11” x 7.5” x 3” (27.9 cm x 19.1 cm x 7.6 cm)
weight	5.2 lbs (2.4 kg)
