Prolitec GENIE User Manual

Genie 17Chapter 5 OPERATING INSTRUCTIONS
Using the online SD card programming tool
The online SD card programming tool can be found at http://airqtools.com/sdcard/
1. Multiple programs sets can be created, which are unique to the user, and stored in a list.
2. Create a program set using the create program button.
• Each program set will require a name.
• Each program set can contain 21 unique programs, which can be turned on or off within the
set.
• Programs, identied by number 1-21, include a day or days, on/off times, and intensity
settings.
• The tool will warn the user of overlapping programs.
• Programs sets need to be saved.
3. Edit an existing program set using the edit button to the right of the program name.
4. Copy an existing program set using the copy button to the right of the program name. This can
be especially useful for quickly duplicating a very similar set of programs.
5. Delete an existing program set using the delete button to the right of the program name.
6. Export an existing program set using the export button to the right of the program name.
• A .zip le containing your program set (schedule.txt), the latest rmware (discover.hex), and
the nal instruction for use (readme.txt) will download to your computer.
• Insert an SDHC card and format it FAT32.
• Copy the les needed (schedule.txt for programs, discover.hex for rmware) to the top level
directory of the card (not in a folder or .zip le).
7. Insert the SD card into the appliance, with the label side down.
Loading new rmware from an SD card
1. Copy discover.hex to a FAT32 formatted SD card.
2. Insert the SD card, with the label side down.
3. Press the reset button, and the ve buttons will light in sequence
from left to right.
4. The : and E buttons will light alternately.
5. Press and hold : for one second, and the display will show LOAD for
5

Prolitec GENIE Specifications

Power

input voltage	100 – 240VAC
input current	0.6A max
output voltage	15VDC
output current	1.2 A
battery type	Lithium 3V, #CR2032

Operating Environment

working temperature	0˚ to 40˚ C
working humidity	85% or less

Capacity

liquid capacity	500 mL cartridges
service area	Up to 15, 000 cu. ft. (425 m[3])

Weight and Dimensions

dimensions	11” x 7.5” x 3” (27.9 cm x 19.1 cm x 7.6 cm)
weight	5.2 lbs (2.4 kg)
