Prolitec GENIE User Manual

Genie 13Chapter 5 OPERATING INSTRUCTIONS
Setting Up the Cartridge
1. Use the key to unlock and open the door.
2. Prepare the cartridge.
• Remove the big plug from the air-stem port (b) on the at surface (back side) of the
cartridge.
• Remove the plug from the top outlet port (a) of the cartridge.
(a) Outlet Plug
(b) Air-stem Plug
3. Insert the airstem into the air-stem port in the cartridge head. Rotate air stem to locked
position.
5

Prolitec GENIE Specifications

Power

input voltage	100 – 240VAC
input current	0.6A max
output voltage	15VDC
output current	1.2 A
battery type	Lithium 3V, #CR2032

Operating Environment

working temperature	0˚ to 40˚ C
working humidity	85% or less

Capacity

liquid capacity	500 mL cartridges
service area	Up to 15, 000 cu. ft. (425 m[3])

Weight and Dimensions

dimensions	11” x 7.5” x 3” (27.9 cm x 19.1 cm x 7.6 cm)
weight	5.2 lbs (2.4 kg)
