Section II - QCS100
QCS100 Installation
Correct Incorrect
The condensation collecting
line must at all times have a
downward slope of at least
1°.
Avoid water pocket of the
feed hose to the pressure
relief chamber.
Avoid sagging of the hose
to the waste water outlet.
6 Quincy Compressor-QCS High Efficiency Emulsion Separators
