Appendix A - Dimensional Drawings & Technical Data
QCS450
20.5
(520)
14.4
(365)
22.4
(570)
24.0
(610)
18.1 (460)
NOTES:
1) DIMENSIONS ARE IN INCHES (MILLIMETERS).
2) DO NOT REMOVE THE 1/2 INCH CONNECTOR
WHEN USING A 1 INCH HOSE.
14.4
(365)
CONDENSATE INLET
SEE DETAIL
INLET DETAIL
SEE NOTE 2
0.5 (13)
1.0 (25)
28 Quincy Compressor-QCS High Efficiency Emulsion Separators
