20 DSM25 Owner’s Handbook
3. Drill a 9/64" (3mm) pilot hole at each of the marked locations.
Note:
For fiberglass with a gelcoat surface, you should overdrill the surface to prevent the
gelcoat from chipping when driving in the screw. Before drilling the pilot hole, hand drill
the marked location with an oversized bit and countersink to approximately 3/8" (9mm)
diameter.
4. Drive the supplied #8 screws into the pilot holes. Screw them in about half way.
x2
D7740-1
Vertical
x2
D7741-1
Vertical
