57
Appendix: Specifications
General
Sounder Features
Approvals:
CE - conform to EN60945:2002
Size: 6.77" x 8.19" x 1.85" (172 x 208 x 47mm)
Weight: 0.85 lbs (386 g)
Mounting: Dash
Power: Supplied by A65 display
Environmental:
Operating Range:
Storage Range:
Humidity:
Waterproof to IPX-7
+14°F to +122°F (–10°C to +50°C)
–4° F to +158°F (–20°C to +70°C)
up to 95% at 35°C non-condensing
Connectors 7 pin transducer
8 pin A65 network
Output Power: Adjustable to 500 watts RMS
Frequency Dual 50 kHz and 200 kHz
Pulse Length: 100 µsec to 4 msec
Max. Transmit Rate: 1580 pulses / min. @ 50’ range
Depth: 3 to 3000 ft (1000 m)
Transducer: Transom-mount, Trolling motor-
mount, in-hull, or thru-hull
81254.book Page 57 Monday, March 6, 2006 2:29 PM
