Raymarine E140 User Manual

3.10Fastheadingconnection
IfyouwishtouseMARPA(radartargetacquisition)functions
onasystemwithoutaSeaT alk
ng
autopilotthenyouwillrequire
adedicatedFastheadingconnection.Theconnectionuses
NMEA0183andcanbemadetoeitheracompatibleRaymarine
autopilotoradedicatedFastheadingsensor.Ifyoursystemincludes
aRaymarineSPXcoursecomputerconnectedusingSeaTalk
ng
then
youwillnotneedtheseparateFastheadingconnection.
TypicalFastheadingfromNMEA0183compatibleautopilot
D11220-2
NMEA0183
1 2
4
3
5
Note:TheconnectioncanbemadeintoanyNMEA0183port.
1.Display
2.Autopilotcoursecomputer
3.AutopilotconnectedviaNMEA0183(Fastheadingandother
relevantdata)
4.Autopilotcontroller
5.Fluxgatecompass
Cablesandconnections39
