9.4TimeandDateset-up

Youcanspecifyyourpreferenceforthewaythattimeanddatewillappearinallapplications.

MenuitemDescriptionOptions

DateFormat

Allowsyoutospecifythepreferredformatforthe

displayofdateinformationinallapplications.

•MM:DD:YY(Month,Day,Year)

•DD:MM:YY(Day,Month,Year)

TimeFormat

Allowsyoutospecifythepreferredformatforthe

displayoftimeinformationinallapplications.

•12hr

•24hr

LocalTime:UTCAllowsyoutospecifythelocaltimezonethatwill

beused,intermsofanoffsetfromUTC(Universal

CoordinatedTime),in0.5hourincrements.

•–13to+13hours(in0.5hour

increments)
