Raymarine e95 User Manual

17.2Routes
Arouteisaseriesofwaypointstypicallyusedto
assistwithpassageplanningandnavigation.
Arouteisdisplayedonscreenasaseriesof
waypointslinkedbyaline.
D
11750-1
Routefeatures
Therearearangeofroutefeaturesforbuilding,
navigatingandmanagingroutes.
Theroutefeaturesallowyouto:
•Buildandsavearouteforusewhenrequired
(storedintheroutelist).
•Navigate(follow)routes.
•Manageandeditroutesstoredonthesystem.
•Buildaroutefromanexistingtrack.
Routefeaturesareaccessedfromthechart
application:
•byselectinganexistingroute.
•byusingtheBuildRouteoptionfromthechart
contextmenu.
•byusingtheChartapplicationmenu:Menu>
Navigate>FollowRouteorBuildRoute.
Note:TheRouteListcanalsobeaccessedfrom
thehomescreenbyselectingMyDataandthen
Routes.
Routebuilding
Aroutecanconsistofacombinationof:
•Newwaypoints
•existingwaypoints
•anexistingtrack
Aseachwaypointisadded,itisassignedanindex
numbercorrespondingtoitspositionintheroute
anddrawnonthechartusingthecurrentlyspecied
symbol.Thefollowingshouldbenoted:
•Whenarouteisbeingbuiltitisnotactiveanddoes
notaffectanycurrentnavigation.
•Youcannotsaveanewrouteifanyofthe
waypointswithinitarecurrentlyactive.
Buildingaroute
Youcanbuildarouteonatouchscreenmultifunction
displaybyfollowingthestepsbelow.
D11762-1
Fromthechartapplication:
1.Selectandholdalocationonscreen.
Thechartcontextmenuisdisplayed.
2.SelectBuildRoute.
Thebuildroutemenuisdisplayed.
3.Selectalocationonscreentobethestarting
position.
4.Selectrelevantlocationstoplacesubsequent
waypointsinorder.
Therouteissavedanddisplayedaseach
waypointisplaced.
5.WhencompleteselectFinishBuild.
Thenishroutebuildpopupmessageis
displayed.
6.SelectFollowtoimmediatelyfollowtheroute.or
7.SelectEdittochangetheroutenameorchange
theroutecolor.or
8.SelectExittosavetherouteandreturntothe
chartapplication.
Note:Ifyouplaceawaypointatthewrong
position,selectUndoWaypointfromtheRoute
Menu.
Buildingaroute
Fromthechartapplication:
1.SelectMenu.
2.SelectNavigate.
3.SelectBuildRoute.
Thebuildroutemenuisdisplayed.
4.SelectPlaceWpt.
5.UsingtheJoystickselectalocationonscreen.
6.PresstheOkbuttontoplacetherstwaypoint
intheroute.
7.UsetheJoystickandtheOkbuttontoplace
subsequentwaypoints.
Therouteissavedanddisplayedaseach
waypointisplaced.
8.WhenyourrouteiscompleteselectFinishBuild.
Thenishroutebuildpopupmessageis
displayed.
9.SelectFollowtoimmediatelyfollowtheroute.or
10.SelectEdittochangetheroutenameorchange
theroutecolor.or
Waypoints,RoutesandTracks
217

Raymarine e95 Specifications

General

Display Size	9 inches
Display Resolution	800 x 480 pixels
Touchscreen	Yes
Chartplotter	Yes
Sonar Support	Yes
Radar Compatible	Yes
Wi-Fi	Yes
Bluetooth	Yes
Networking	NMEA 2000, Ethernet
Video Input	Yes
Waterproof Rating	IPX6
Display Type	Color LCD
Cartography	Navionics
Operating Voltage	12 V DC / 24 V DC
Weight	3.2 lbs
GPS Receiver	Built-in 50 channel
