20.11Resettingminimumand

maximumreadings

Minimumandmaximumreadingssortedonthe

displaycanberesetfromtheDataapplication.

FromtheDataapplication,withthedatayouwantto

resetdisplayedonscreen:

1.SelectMenu.

2.SelectDataResets.

3.Selectthedataitemyouwanttoreset.

Thereadingisreset.

Note:Resetswillonlybeavailablefordataitems

thatarecurrentlydisplayedonscreen.

20.12Resettingalldatapages

Youcanresetthedatapagesinthedataapplication

tothefactorydefaults.

1.SelectMenu.

2.SelectResetAllPages.

Theconrmresetpopupmessageisdisplayed.

3.SelectYestoresetorNotocanceltheaction.

Note:Resettingallpageswillrestoreyour

pre-conguredpagestodefaultsettingsand

removeanycustompagesthathavebeencreated.

NumberofenginesandmaximumRPMsettings

willnotbechangedduringthereset.

Dataapplication

309
