48 Ray240 User Manual
3.4 Typical installation
A typical installation for the Ray 240 is shown below:
Power
Red 12V DC
Black 0V
VOL/PWRVOL/PWR
To Antenna
D7175-1
NMEA
SeaTalk/GPS
Optional 2nd station
Hailer horn
