Rheem RGFG User Manual

113
FIGURE 75
NAVIGATE TO DESIRED USER MENU AND SELECT.
FIGURE 74
NAVIGATE TO FURNACE AND SELECT.
VIEWING FURNACE
USER MENUS WITH THE
(-)HC-TST550CMMS
THERMOSTAT
To enter a particular user menu on
the (-)HC-TST550CMMS, full color
communicating thermostat follow
the directions below.
Use the section of this manual
titled Communicating Systems
under the sub-section titled User
Menus to navigate through the
user menus.
FIGURE 72
ENTER THE ADVANCED INSTALLER MENU.
FIGURE 73
NAVIGATING TO COMMUNICATING DEVICES AND SELECT.
3. From the devices
listed, use the up
and down arrow
keys to highlight the
selection titled
Furnace. Next,
Press the “M” Key.
The next screen
below will appear.
4. The furnace menu
options will appear.
Use the up and down
arrow keys to select
the desired menu.
Next, press “M
” to
enter the desired
menu. Next, the next
screen below will
appear.
FIGURE 76
NAVIGATE THE USER MENUS USING UP AND DOWN ARROW KEYS.
5. Use the up and down
arrow keys to view the
menu items.
6. To escape from this
menu, press the Enter
(to return to the fur-
nace user menus) or
Home button or just
wait a few minutes
and the main screen
will appear again.
2. The ADVANCED
INSTALLER MENU
is displayed. Use
the up and down
arrow keys to high-
light
Communicating
Devices. Next,
press the “M” key.
The next screen
below will appear.
1. From the main
screen, press the left
and right arrow keys
together at the same
time for at least 3
seconds. The next
screen below will
appear.
Home
Enter
Home
Enter
Home
Enter
Home
Enter
