CONVENTIONAL THERMOSTAT WIRING
The (-)H2V series air handler is shipped with “On Demand Dehumidification” (ODD)
turned OFF. On Demand Dehumidification is used in conjunction with a traditional
24VAC thermostat equipped with an on-board humidity sensor. Activate ODD by turning
DIP switch 7 ON. ODD operation is controlled by the indoor humidity sensed at the ther-
mostat. Operation is:
Normal Humidity (humidity BELOW the thermostat set point):
H
igh Humidity (humidity ABOVE the thermostat set point):
The (-)H2V air handler is programmed to provide maximum efficiency and optimum
humidity removal. When high humidity is detected, the air handler reduces cooling air-
flow defined in Table 6.
IMPORTANT: The DIP switches are active only when using conventional a 24VAC ther-
mostat. If using the Comfort Control
2
System™, refer to Section 5.4 for adjusting air-
flows.
NOTE: ODD airflow adjustments are active for cooling operation only. They are ignored
when the heat pump is in heating mode or when electric heat is activated.
6.16 COOLING DELAY PROFILES (-)H2V
Cooling delay profiles are not available when the H2V air handler is controlled using a
conventional 24VAC thermostat. These profiles are available only when the air handler
is wired for the Comfort Control
2
System™. Refer to Section 5.4 for the Comfort Control
2
Cooling Delay Profiles.
TABLE 12
ODD AIRFLOW REDUCTION (-)H2V
Airflow (CFM)
2nd Stage (Y2) 1st Stage (Y1)
Switch 2
Position
Switch 1
Position
Outdoor
Unit
(-)H2V
2421HT (-)ASL-025 OFF OFF 650 500
3624HT (-)ASL-037 ON OFF 950 750
3624HT (-)ASL-039 OFF OFF 950 650
4824HT (-)ASL-048 OFF OFF 1275 800
6024HT (-)ASL-060 OFF OFF 1350 850
2421HT (-)ARL-025 ON OFF 650 500
3624HT (-)ARL-038 ON OFF 950 750
4824HT (-)ARL-049 ON OFF 1275 950
6024HT (-)ARL-061 ON OFF 1350 1025
O
Normal Humidity Result
A 24VAC signal is applied to
the ODD terminal
Full rated airflow is delivered
by the blower
O
High Humidity Result
No signal applied to the ODD
terminal
Airflow is reduced by a preset
amount to increase latent
capacity
