OUTDOOR UNIT ROMH18AFXZJ
3. Installation space
3-1. Model: ROMH18AFXZJ
 S
pace requirement
Provide sufficient installation space for product safety.
z Single outdoor unit installation
• When the upper space is open:
• When there is an obstruction in the upper space:
Unit: in (mm)
When there are obstacles at the rear only. When there are obstacles at the rear and sides.
When there are obstacles at the front only. When there are obstacles at the front and rear.
Unit: in (mm)
When there are obstacles at the rear and
above.
When there are obstacles at the rear, sides, and
above.
4 (100) or more
10 (250)
or more
12 (300)
or more
4 (100)
or more
24 (600)
or more
24 (600)
or more
4 (100)
or more
12 (300)
or more
Max. 19
(500)
24 (600)
or more
40 (1,000)
or more
4 (100)
or more
10 (250)
or more
20 (500)
or more
Max. 19
(500)
