Rheem RIDH07AVFJ User Manual

- 41 -
MULTI TYPE 2, 3, 4 ROOMS TYPE
4. Dimensions
4-1. Compact cassette type
 Models: RICH7AVFJ, RICH9AVFJ, RICH12AVFJ, and RICH18AVFJ
(Drain hose)
20-7/8 (530): Hanging bolt position
4 (102)
5-5/16
(135)
9-13/16 (250)
27-9/16 (700)
27-9/16 (700)
2-15/16 (75)
1-3/16 (30)
1-3/16 (30)
10-5/16 (262)
21-1/4 (540): Hanging bolt position
22-7/16 (570): Indoor unit
22-13/16 to 26 (580 to 660) : Ceiling openings
• Cassette grille mounting state
T op view
5-14/16 to 7-7/8 (150 to 200)
Min. 17-11/16 (450)
Min. 17-11/16 (450)
Maintenance space
Side view
8-7/16 (215)
4-13/16 (123)
2-5/16 (58)
4-1/2 (114)
5-3/4 (146)
4-1/4 (108)
4 (102)
9-5/8 (245)
1-3/16 (30)
1-9/16 (40)
3-7/8 (99)
Drain port
Control box
Ceiling
Drain port
Be sure to leave
maintenance space
for future service
at the designated
position.
Bottom view
1-3/16 (30) 1-15/16 (49)
Side view
Unit: in. (mm)
