MULTI TYPE 2, 3, 4 ROOMS TYPE
3-2. Slim duct type
Model name
RIDH7AVFJ RIDH9AVFJ RIDH12AVFJ
Power supply 208/230 V ~ 60 Hz
Available voltage range 187—264 V
Capacity Btu/h class 7,000 9,000 12,000
Input power W 33 49 58
Running current A 0.30 0.30 0.35
Fan
Airflow rate
Cooling
HIGH
CFM (m
3
/h)
324 (550) 353 (600) 383 (650)
MED 288 (490) 324 (550) 353 (600)
LOW 277 (470) 294 (500) 324 (550)
QUIET 259 (440) 265 (450) 283 (480)
Heating
HIGH 324 (550) 353 (600) 383 (650)
MED 288 (490) 324 (550) 353 (600)
LOW 277 (470) 294 (500) 324 (550)
QUIET 259 (440) 265 (450) 283 (480)
Type × Q'ty Sirocco fan × 2
Motor output W 80 81
Recommended static pressure inWG (Pa) 0 to 0.36 (0 to 90)
Sound pressure level *
Cooling
HIGH
dB (A)
28 28 29
MED 26 27 28
LOW 25 26 27
QUIET 24 25 26
Heating
HIGH 28 28 29
MED 26 26 28
LOW 25 25 27
QUIET 24 24 24
Heat exchanger type
Dimensions (H × W × D) in (mm)
11-9/16 × 19-11/16 × 1-1/16
(294 × 500 × 26.6)
11-9/16 × 19-11/16 × 1-9/16
(294 × 500 × 39.9)
Fin pitch FPI 20
Rows × Stages 2 × 14 3 × 14
Pipe type Copper tube
Fin type Aluminum
Enclosure
Material Galvanized steel sheet
Color -
Dimensions
(H × W × D)
Net
in (mm)
7-13/16 × 27-9/16 × 24-7/16 (198 × 700 × 620)
Gross 10-13/16 × 37-3/16 × 30-3/8 (274 × 945 × 772)
Weight
Net
lb (kg)
37 (17) 40 (18)
Gross 49 (22) 51 (23)
Connection pipe
Size
Liquid
in (mm)
Ø1/4 (Ø6.35)
Gas Ø3/8 (Ø9.52)
Method Flare
Drain hose
Material Hard PVC
Size in (mm) Ø 3/4 (I.D.), Ø 1-1/16 (O.D.) [Ø 20.7 (I.D.), Ø 26.6 (O.D.)]
Operation range
Cooling
°F (°C) 64 to 90 (18 to 32)
%RH 80 or less
Heating °F (°C) 60 to 88 (16 to 31)
Remote controller type Wired (Wireless [option])
NOTES:
• Specifications are based on the following conditions.
– Standard static pressure: 0.10 inWG (25 Pa)
• The protective function might work when using it outside the operation range.
• *Sound pressure level:
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
