Ricoh Aficio C3002 User Manual

5. Print
This chapter describes frequently used printer functions and operations. For the information not included
in this chapter, see Print on the supplied CD-ROM.
Quick Install
You can install the printer drivers easily from the CD-ROM provided with this machine.
Using Quick Install, the PCL 6 printer driver is installed under network environment, and the Standard
TCP/IP port will be set.
When the machine is connected to a client computer via parallel connection, the printer port is set to
[LPT1].
• Manage Printers permission is required to install the drivers. Log on as an Administrators group
member.
1. Quit all applications. (Do not close this manual.)
2. Insert the provided CD-ROM into the computer's CD-ROM drive.
If the [AutoPlay] dialog box appears, click [Run AUTORUN.EXE].
3. Select an interface language, and then click [OK].
4. Click [Quick Install].
5. The software license agreement appears in the [License Agreement] dialog box. After
reading the agreement, click [I accept the agreement.], and then click [Next].
6. Select the machine model you want to use in the [Select Printer] dialog box.
For network connection via TCP/IP, select the machine whose IP address is displayed in [Connect
To].
For parallel connection, select the machine whose printer port is displayed in [Connect To].
7. Click [Install].
8. Configure the user code, default printer, and shared printer as necessary.
9. Click [Continue].
The installation starts.
If the [User Account Control] dialog box appears, and then click [Yes] or [Continue].
10. Click [Finish].
When you are prompted to restart your computer, restart it by following the instructions that
appear.
11. Click [Exit] in the first window of the installer, and then take out the CD-ROM.
101

Ricoh Aficio C3002 Specifications

General

Print Speed	30 ppm (B/W), 30 ppm (Color)
Resolution	1200 x 1200 dpi
Copy Resolution	600 x 600 dpi
Paper Capacity (Maximum)	4, 400 sheets
Duplex Printing	Yes
ADF Capacity	100 sheets
Standard Features	Copy, Print, Scan
Hard Disk Drive	250 GB
Interface	USB 2.0, Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Printer Languages	PCL5c, PCL6, PostScript 3
Paper Capacity (Standard)	1, 200 sheets
Scanner Type	Color Flatbed with ADF
Scanner Resolution	600 dpi
Network Connectivity	Ethernet
Power Consumption	1.7 kW (Maximum)
Power Source	120V/60Hz/15A
Optional Features	Fax, Additional Paper Trays, Finisher
Network Protocol	TCP/IP
Scan Formats	PDF, JPEG, TIFF
Scan To	Email, Folder, USB
Memory	1.5 GB (Standard), 1.5 GB (Maximum)
