Ricoh Aficio C3002 User Manual

Copying onto Custom Size Paper from the
Bypass Tray
Paper that has a horizontal length of 148.0–457.2 mm (5.83–18.00 inches) and a vertical length of
90.0–305.0 mm (3.55–12.00 inches) can be fed in from the bypass tray. Note however that the
limitation on the horizontal and vertical length range will vary depending on which options are installed.
• When prints are delivered to the trays of the finisher:
Horizontal length: 148.0–457.2 mm (5.83–18.00 inches), vertical length: 100.0–305.0 mm
(3.94–12.00 inches)
• When prints are delivered to the internal tray 2:
Horizontal length: 148.0–432.0 mm (5.83–17.00 inches), vertical length: 93.0–297.0 mm
(3.67–11.69 inches)
1. Load the paper face down in the bypass tray.
[Bypass] is automatically selected.
2. Press the [ ] key.
3. Press [Paper Size].
4. Press [Custom Size].
5. Enter the horizontal size with the number keys, and then press [ ].
6. Enter the vertical size with the number keys, and then press [ ].
7. Press [OK] twice.
8. Place the originals, and then press the [Start] key.
3. Copy
78

Ricoh Aficio C3002 Specifications

General

Print Speed	30 ppm (B/W), 30 ppm (Color)
Resolution	1200 x 1200 dpi
Copy Resolution	600 x 600 dpi
Paper Capacity (Maximum)	4, 400 sheets
Duplex Printing	Yes
ADF Capacity	100 sheets
Standard Features	Copy, Print, Scan
Hard Disk Drive	250 GB
Interface	USB 2.0, Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Printer Languages	PCL5c, PCL6, PostScript 3
Paper Capacity (Standard)	1, 200 sheets
Scanner Type	Color Flatbed with ADF
Scanner Resolution	600 dpi
Network Connectivity	Ethernet
Power Consumption	1.7 kW (Maximum)
Power Source	120V/60Hz/15A
Optional Features	Fax, Additional Paper Trays, Finisher
Network Protocol	TCP/IP
Scan Formats	PDF, JPEG, TIFF
Scan To	Email, Folder, USB
Memory	1.5 GB (Standard), 1.5 GB (Maximum)
