3. Press the [ ] or [ ] key to select [Network], and then press the [OK] key.
4. Press the [ ] or [ ] key to select [NW Frame Type], and then press the [OK] key.
5. Press the [ ] or [ ] key to select the frame type to use, and then press the [OK] key.
6. Press the [Menu] key to return to the initial screen.
7. Print a configuration page to confirm the settings.
• For details about printing the configuration page, see p.44 "Test Printing".
Setting the Ethernet Speed
You can set the speed that the printer will use for Ethernet communications. In most cases, this should be
left on the default setting, [Auto Select]. This setting allows two interfaces to automatically determine the
optimum speed when they are connected.
Router/HUB
Printer
[10Mbps Half
Duplex]
[10Mbps Full
Duplex]
[100Mbps
Half Duplex]
[100Mbps Full
Duplex]
[Auto Select]
10 Mbps half
duplex
- - -
10 Mbps full
duplex
- - - -
Ethernet Configuration
81
