Names and Functions of the Control Panel
The touch panel (Smart Operation Panel) that displays the operation screen of the machine is referred to as the
"Control Panel".
On both sides of the control panel, interfaces for connecting external devices and slots to insert an SD
card/USB flash memory device are provided.
Even when the screen is turned off, the LED indicators on the frame of the control panel show the status of
the machine.
Media slots
Insert an SD card or USB flash memory device. You can store the scanned data or print the file
stored on the media.
Use an SD memory card or SDHC memory card with a maximum capacity of 32 GB. You
cannot use an SDXC memory card.
Use the media formatted in FAT16 or FAT32.
Certain types of USB flash memory devices cannot be used in the machine.
A USB extension cable, hub, or card reader cannot be used.
If the power of the machine is turned off or the media is removed from the machine while
the machine is reading the data in the media, check the data in the media.
1.
Touch Panel/Interface

Ricoh IM 9000 Specifications

General

Resolution	1200 x 1200 dpi
Paper Capacity (Maximum)	8, 700 sheets
First Output Speed	3.9 seconds
Paper Input Capacity (Standard)	4, 300 sheets
Paper Weight	52 - 300 g/m²
Duplex Printing	Standard
Standard Memory	2 GB
Hard Disk Drive	320 GB
Power Source	220 - 240 V, 50/60 Hz
Maximum Paper Size	SRA3
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	90 ppm
Paper Size	A3, A4, A5, B4, B5
Processor	Intel Atom Processor Bay Trail
Network Connectivity	Ethernet 10 base-T/100 base-TX/1000 base-T, USB 2.0
