User GuideIM 7000/8000/9000
Top Page>Introduction and Basic Operations>Using Web Image Monitor
Using Web Image Monitor
Web Image Monitor is a screen to confirm the machine status and settings on the computer.
When the machine and a computer can be connected to a network, you can access to Web Image Monitor by
entering the IP address of the machine on the address bar of the Web browser.
Accessing to Web Image Monitor
Example: when the IP address of the machine is "192.168.1.10"
If SSL is specified
https://192.168.1.10/
If SSL is not specified
http://192.168.1.10/
When you do not know whether SSL is specified on the machine, enter the address starting with https.
When you fail the connection, enter the address starting with http.
When entering the IPv4 address, do not enter "0" for each segment. If "192.168.001.010" is entered, you
cannot access the machine.
Enter the IP address of the machine in the address bar of the Web browser.
Confirming the machine status or settings on the top page of Web Image
Monitor.

Ricoh IM 9000 Specifications

General

Resolution	1200 x 1200 dpi
Paper Capacity (Maximum)	8, 700 sheets
First Output Speed	3.9 seconds
Paper Input Capacity (Standard)	4, 300 sheets
Paper Weight	52 - 300 g/m²
Duplex Printing	Standard
Standard Memory	2 GB
Hard Disk Drive	320 GB
Power Source	220 - 240 V, 50/60 Hz
Maximum Paper Size	SRA3
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	90 ppm
Paper Size	A3, A4, A5, B4, B5
Processor	Intel Atom Processor Bay Trail
Network Connectivity	Ethernet 10 base-T/100 base-TX/1000 base-T, USB 2.0
