Ricoh SP 211 User Manual

Removing Jammed Paper from Tray 1
1. Pull Tray 1 halfway out, and check for jammed paper. If there is jammed paper, remove it
carefully.
DCT012
2. Carefully slide Tray 1 back in until it stops.
3. Open the front cover, and then carefully lower it.
DCT027
4. Carefully pull out the print cartridge horizontally, holding its center.
DCT024
• Do not shake the removed print cartridge. Doing so can cause remaining toner to leak.
• Place the print cartridge on paper or similar material to avoid dirtying your workspace.
10. Troubleshooting
212 opal-p2_mf2_com_user_guide_00142150_eng.xml
Draft 2014/01/07

Ricoh SP 211 Specifications

General

Print Technology	Laser
Resolution	1200 x 600 dpi
Paper Input Capacity	150 sheets
Connectivity	USB 2.0
Dimensions	402 x 360 x 165 mm
Weight	7.2 kg
First Print Out Time	10 seconds
Duplex Printing	Manual
Print Speed	22 ppm
Supported Operating Systems	Windows, Mac
