Riello Array AR 399 SE User Manual

21
INSTALLATION
Fig. 14 Installation
22.24”
24.80”
Fig. 15 Array AR SE
2.56’’
ø 0.41’’
ø 0.41’’
Fig. 16 Anchoring bolt detail
3.6 Installation in older systems and systems
requiring modications
When installing these boilers in older systems or systems requiring
modications, always perform the following checks:
− Make sure that the ue is able to withstand the tempera-
ture of the combustion gases and that it has been designed
and made in compliance with applicable standards. The
ue must also be as straight as possible, sealed, insulated
and not blocked or choked. See section “Combustion gas
exhaust” for any additional information.
− Make sure that the electrical supply system has been in-
stalled by a qualied electrician in compliance with appli-
cable standards
− Make sure that the fuel feed line and any storage tank are
made and installed in compliance with applicable stan-
dards
− Make sure that expansion tank(s) are big enough to contain
the additional volume generated by thermal expansion
− Make sure that the ow rate, head and direction of ow of
the pumps are suitable and correct
− The system has been washed, cleaned of mud and grime
and water seals have been checked
− A treatment system is tted when the supply/rell water
has values other than those indicated in section “Water
Chemistry Guidelines”
9
NOTE: The manufacturer declines all responsibility for damage
caused by incorrectly constructed ue systems.
3.7 Boiler Location
− This boiler is suitable only for indoor installations.
− To operate properly and safely, this boiler requires a con-
tinuous supply of air for combustion. Install this boiler in a
clean, dry location with adequate air supply.
− Do not locate this boiler in an area where it will be subject
to freezing.
− The boiler should be located close to a oor drain in an area
where leakage from the appliance or connections will not
result in damage to the adjacent area or to lower oors in
the structure.
− DO NOT install this appliance in any location where gasoline
or ammable vapors are likely to be present.
− DO NOT install this appliance on top of carpet or combusti-
ble ooring.
− Appliance must be installed on a concrete level service pad
(3.5” - 4” minimum recommended height).
− Maintain required clearances 2” (50.8mm) from combusti-
ble surfaces.
3.8 Water Quality Guidelines
Excessive water hardness causing a lime buildup in the stainless
steel coils or tubes is not a fault of the appliance and is not covered
by warranty. Water hardness must fall within the following limits:
Parameters Units Value
General feature - Colorless, no sediment
PH value PH Min 6.5; Max 9
Dissolved Oxygen mg/l < 0,05
Total iron (Fe) mg/l < 0,3
Total copper (Cu) mg/l < 0,1
Na
2SO3 mg/l < 10
N
2H4 mg/l < 3
PO
4 mg/l < 15
