Rigol DS1000Z Series Quick Guide

RIGOL
DS1000Z Quick Guide
8
Front Panel Overview
Figure 9 Front Panel Overview
No.
Description
No.
Description
1 MENU 10 Power Key
2 LCD 11 USB HOST Interface
3 Knob 12 Function Menu Setting Softkeys
4 Function Menus 13 Analog Channel Input Area
5 CLEAR 14 VERTICAL Control Area
6 AUTO 15 HORIZONTAL Control Area
7 RUN/STOP 16 TRIGGER Control Area
8 SINGLE 17
Probe Compensation Signal Output
Terminal/ Ground Terminal
9 Help/Print -- --
3 4 5 6 7 8 9
1 2
10 11 12 13 14 15 16 17
