RIGOL Chapter 9 Reference Waveform
9-6 MSO4000/DS4000 User’s Guide
To Import from the Reference Waveform File
Users can import the reference waveform stored in the internal memory or external
USB storage device (only when a USB storage device is detected) to the current
reference waveform channel.
1. Please turn on the desired reference waveform channel and set it as the current
reference waveform channel by referring to “To Turn the Reference
Waveform Channel On/Off” and “To Select the Current Reference
Waveform Channel”.
2. Press Import to enter the file recall interface. Please refer to the relative
descriptions in “
Store and Recall” to import the specified reference waveform
file (*.ref) to current reference waveform channel.
