Reference Clock
This oscilloscope can output the internal 10 MHz sample clock signal from the
[10MHz In/Out] connector at the rear panel as well as receive an external 10 MHz
clock signal from the connector. This function can be used to synchronize multiple
oscilloscopes.
Press Utility and press RefClock to select the desired clock type.
 ClockOutput: output the internal 10 MHz clock signal of the oscilloscope from
the [10MHz In/Out] connector at the rear panel.
 ClockInput: the oscilloscope receives the external 10 MHz clock signal from the
[10MHz In/Out] connector at the rear panel.
