Rigol MSO4000 series User Manual

RIGOL Chapter 2 Vertical System Setting
2-8 MSO4000/DS4000 User’s Guide
Passive Probe
1. Probe Type
Probe Type displays “Nor-Probe”; for example, when RIGOL RP3500A probe is
connected.
2. Ratio
For some normal passive probes, the oscilloscope can identify the probe ratio
automatically. If not, press Ratio and turn the multi-function knob to select
the corresponding probe ratio; or press Ratio continuously to switch the current
probe ratio. The probe ratios available are listed in
Table 2-1.
Table 2-1 Probe Attenuation Coefficient
Probe Ratio
Attenuation Coefficient
(waveform display amplitude : actual waveform amplitude)
0.01X
0.02X
0.05X
0.1X
0.2X
0.5X
1X
2X
5X
10X
20 X
50 X
100 X
200 X
500 X
1000 X
0.01:1
0.02:1
0.05:1
0.1:1
0.2:1
0.5:1
1:1
2:1
5:1
10:1
20:1
50:1
100:1
200:1
500:1
1000:1
