Robomow RC308u User Manual

30
31
• Wires leading to and from an island should be fastened with
the same peg
• Perimeter Islands should either be rectangular or round
Set the Perimeter
Wire clockwise around
the obstacle, otherwise
the mower will drive
into the Perimeter
Island or won’t be
able to mow the
area around it
properly.
TIPS
D. Protect Soft Obstacles
Objects such as flower beds, ponds, or small trees must be
protected by setting Perimeter Islands.
Keep min. 1 m (3.3 ft) between
islands; if obstacles are closer
together, use one island
If the distance between an island and the
perimeter wire is lower than 1 m (3.3 ft),
make the obstacle part of lawn’s edge.
Perimeter Wire position
Perimeter Wire

Robomow RC308u Specifications

General

Type	Robotic lawn mower
Noise level	69 dB
Cutting width	280 mm
Grass catcher	-
Product color	Green
Cutting system	Rotary blades
Number of wheels	3 wheel(s)
Maximum working climb	36 %
Recommended lawn area	800 m²
Maximum cutting height	60 mm
Minimum cutting height	15 mm
Grass collecting volume	- L
Cutting clearance adjustment	6
Battery type	Built-in
Power source	Battery
Charging time	1.5 h
Battery voltage	26 V
Battery capacity	3 Ah
Battery life (max)	70 min
Battery technology	Lithium
Power consumption per month (max)	18 kWh

Weight and Dimensions

Depth	460 mm
Width	630 mm
Height	210 mm
Weight	11400 g
