Robomow RC308u User Manual

50
51
Adding Sub Zones
If your lawn has additional zones and they are connected to
your main zone by a narrow passage (we call such zones
“Sub Zones”), you need to tell your mower how to get to
these zones.
To do this, press “Settings” on mower’s panel for more
than 3 seconds. Scroll to get to menu P022. The table below
describes how to use this menu to program a Sub Zone.
Menu Setting Description
P022 Add Sub-Zone
• Upon entering the menu A1/A2/A3/A4 is displayed. This
is a name of the next available Sub Zone, which you can
program. Press OK
• If the mower is currently not at the Base Station, a
message U044 (“Place the mower in the Base Station”)
will be displayed. Place the mower in the Base Station
and press OK.
• The mower will travel along the perimeter wire to the
Sub Zone on its own.
• When the mower is at least 5 m (16 ft) inside the Sub
Zone, press STOP and select the area size of the Sub
Zone. Press OK.
• The distance to the Sub-Zone’s entry point can be
updated later through menu P023

Robomow RC308u Specifications

General

Type	Robotic lawn mower
Noise level	69 dB
Cutting width	280 mm
Grass catcher	-
Product color	Green
Cutting system	Rotary blades
Number of wheels	3 wheel(s)
Maximum working climb	36 %
Recommended lawn area	800 m²
Maximum cutting height	60 mm
Minimum cutting height	15 mm
Grass collecting volume	- L
Cutting clearance adjustment	6
Battery type	Built-in
Power source	Battery
Charging time	1.5 h
Battery voltage	26 V
Battery capacity	3 Ah
Battery life (max)	70 min
Battery technology	Lithium
Power consumption per month (max)	18 kWh

Weight and Dimensions

Depth	460 mm
Width	630 mm
Height	210 mm
Weight	11400 g
