Robomow RC308u User Manual

Manual
operation
68
69
TIP
If a Sub-Zone is defined, L1 (Main Zone) will be displayed
when you choose an operating mode. Use the arrows to scroll
and choose the required zone to be mowed and press OK.
Manual Operation is used when you want to start a
mowing operation regardless of the mowing schedule.
Press any button to show the display.
If the battery is fully charged,
the start time of the next operation is
displayed, otherwise the current day
and time are displayed.
Operation
Mode
Mowing
with Edge
Mowing
without Edge
Child Lock
is Off
Press the LEFT arrow
once.
Press the RIGHT arrow once.
Child Lock
is On
Press the LEFT arrow,
then press OK.
Press the RIGHT arrow,
then press OK.

Robomow RC308u Specifications

General

Type	Robotic lawn mower
Noise level	69 dB
Cutting width	280 mm
Grass catcher	-
Product color	Green
Cutting system	Rotary blades
Number of wheels	3 wheel(s)
Maximum working climb	36 %
Recommended lawn area	800 m²
Maximum cutting height	60 mm
Minimum cutting height	15 mm
Grass collecting volume	- L
Cutting clearance adjustment	6
Battery type	Built-in
Power source	Battery
Charging time	1.5 h
Battery voltage	26 V
Battery capacity	3 Ah
Battery life (max)	70 min
Battery technology	Lithium
Power consumption per month (max)	18 kWh

Weight and Dimensions

Depth	460 mm
Width	630 mm
Height	210 mm
Weight	11400 g
