Robomow RC308u User Manual

62
63
Automatic
operation
• The Area size setting automatically determines the required
mowing time for your lawn - the duration of a “Mowing Cycle”
• The mower usually performs several consecutive mowing
operations until it completes a full Mowing Cycle
• Each mowing operation starts at predetermined times, once
the mower is fully charged
• You can restrict automatic operation at particular times via
the Inactive Time setting
• Once a Mowing Cycle is completed, the mower will stay in
the Base Station until the next cycle begins
• The interval between mowing cycles is defined by the Mowing
Frequency setting
• If required, extra mowing time can be added via the Mowing
Hours setting to improve mowing results.
Learn how to configure automatic operation and manually
bypass/override it when needed.

Robomow RC308u Specifications

General

Type	Robotic lawn mower
Noise level	69 dB
Cutting width	280 mm
Grass catcher	-
Product color	Green
Cutting system	Rotary blades
Number of wheels	3 wheel(s)
Maximum working climb	36 %
Recommended lawn area	800 m²
Maximum cutting height	60 mm
Minimum cutting height	15 mm
Grass collecting volume	- L
Cutting clearance adjustment	6
Battery type	Built-in
Power source	Battery
Charging time	1.5 h
Battery voltage	26 V
Battery capacity	3 Ah
Battery life (max)	70 min
Battery technology	Lithium
Power consumption per month (max)	18 kWh

Weight and Dimensions

Depth	460 mm
Width	630 mm
Height	210 mm
Weight	11400 g
