Robomow RC308u User Manual

50
51
Are there any Separated Zones?
For lawns that have completely noncontiguous Separated
Zones, the area size of these zones needs to be set separately.
To do this, press “Settings” on the mower’s panel for more
than 3 seconds. Scroll to get to the menu P014.
The table below describes how to use this menu to program
a Separated Zone:
Splicing the Perimeter Wire
(as needed)
• Insert both wire ends into
the leftmost and rightmost
positions on the connector.
• Verify that the wires are fully
inserted into the connector.
• Use a pair of pliers to press
the button on top of the
connector. The button should
be fully pressed, without
damaging the connector.
Screen Setting Description
P014
Add Separated
Zone
• Enables to add of a Separated Zone.
• L2 is displayed for Separated Zone A – press OK.
• Scroll to set the area of the Separated Zone and press OK.
A helpful video
is available
online

Robomow RC308u Specifications

General

Type	Robotic lawn mower
Noise level	69 dB
Cutting width	280 mm
Grass catcher	-
Product color	Green
Cutting system	Rotary blades
Number of wheels	3 wheel(s)
Maximum working climb	36 %
Recommended lawn area	800 m²
Maximum cutting height	60 mm
Minimum cutting height	15 mm
Grass collecting volume	- L
Cutting clearance adjustment	6
Battery type	Built-in
Power source	Battery
Charging time	1.5 h
Battery voltage	26 V
Battery capacity	3 Ah
Battery life (max)	70 min
Battery technology	Lithium
Power consumption per month (max)	18 kWh

Weight and Dimensions

Depth	460 mm
Width	630 mm
Height	210 mm
Weight	11400 g
