Robomow RC308u User Manual

40
41
Make sure the connector is inserted the whole way
up to the white mark.
Connect the DC cable from the Power Supply unit to
the 15 m (50 ft) extension cable.
Consider the following
in order to select a proper
location for the Power
Supply unit:
A. Connect the Power Supply unit
• Select a suitable location
near a power outlet
• Position it outside the lawn
perimeter
• A dry and sheltered
location is preferable
TIP
Power
Supply unit
Base
Station
15 m (50 ft)
Extension cable
[low voltage]

Robomow RC308u Specifications

General

Type	Robotic lawn mower
Noise level	69 dB
Cutting width	280 mm
Grass catcher	-
Product color	Green
Cutting system	Rotary blades
Number of wheels	3 wheel(s)
Maximum working climb	36 %
Recommended lawn area	800 m²
Maximum cutting height	60 mm
Minimum cutting height	15 mm
Grass collecting volume	- L
Cutting clearance adjustment	6
Battery type	Built-in
Power source	Battery
Charging time	1.5 h
Battery voltage	26 V
Battery capacity	3 Ah
Battery life (max)	70 min
Battery technology	Lithium
Power consumption per month (max)	18 kWh

Weight and Dimensions

Depth	460 mm
Width	630 mm
Height	210 mm
Weight	11400 g
