20 Rockwell Automation Publication SYSLIB-RM044D-EN-P - February 2017
PowerFlex 753 Drive (P_PF753)
Val_SpeedFdbkEUMax REAL Maximum of Speed Feedback = MAX (Cfg_SpeedFdbkEUMin, Cfg_SpeedFdbkEUMax).
(engineering units)
Val_LastFaultCode DINT Last drive fault code (enumeration) (Par 951).
SrcQ_IO SINT I/O signal source and quality.
SrcQ Final source and quality:
GOOD 0 = I/O live and confirmed good quality
1 = I/O live and assumed good quality
2 = No feedback configured, assumed good quality
TEST 8 = Device simulated
9 = Device loopback simulation
10 = Manually entered value
UNCERTAIN 16 = Live input, off-specification
17 = Value substituted at device/bus
18 = Value substituted by maintenance (Has and not Use)
19 = Shed, using last good value
20 = Shed, using replacement value
BAD 32 = Signal failure (out-of-range, NaN, invalid combination)
33 = I/O channel fault
34 = I/O module fault
35 = Bad I/O configuration (for example, scaling parameters)
Val_Cmd SINT Device command:
0 = None
1 = Stop
2 = Start forward
3 = Start reverse
4 = Jog forward
5 = Jog reverse
Val_Fdbk SINT Device feedback:
0 = Stopped
1 = Running forward
2 = Running reverse
3 = Accelerating
4 = Decelerating
Val_Sts SINT Device Confirmed Status:
0= Powerup/Unknown
1 = Stopped
2 = Running forward
3 = Running reverse
4 = Jogging forward
5 = Jogging reverse
6 = Stopping
7 = Starting forward
8 = Starting reverse
33 = Disabled
Val_Fault SINT Device fault status:
0 = None
16 = Fail to Start
17 = Fail to Stop
18 = Drive Fault
32 = I/O Fault
34 = Configuration Error
Table 9 - P_PF753 Drive Output Parameters
Output Parameter Data Type Alias For Description
