5 Supplemental Information
5
5-2 SENSOR MAP
Y LIMIT SENSOR
This switch detects the limit in
Y direction.
Z LIMIT SENSOR
This switch detects the limit
in Z direction.
X LIMIT SENSOR
This switch detects the limit
in X direction.
SPINDLE COVER SWITCH
This switch detects whether the
Spindle Cover is opened or closed.
