Roland RD-700NX User Manual

102
Purpose-Oriented Index
This index lists the main setting items relevant to play of the RD-700NX’s keyboard.
Volume Setting
Changing the Volume for the entire RD-700NX
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . [VOLUME] slider (p. 18)
. . . . . . . . . . . . . . . . .[MENU] button
0.System Master Volume (p. 67)
Changing the volume for Individual Layer
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . LAYER LEVEL slider (p. 31)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .[LAYER EDIT] button
Volume (p. 56)
Key Touch and Velocity
Changing the key touch
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . [MENU] button
1. Key Touch (p. 71)
Changing the value of velocity for each Layer
. . . . . . . . . . . . . . . . . . . . . . . . . [LAYER EDIT] button
Velocity Sens (p. 57)
. . . . . . . . . . . . . . . . . . . . . . . . . .[LAYER EDIT] button
Velocity Max (p. 57)
. . . . . . . . . . . . . . . . . . . . . . . [LAYER EDIT] button
Velocity Range (p. 57)
Control
Disabling the Pedal or Bender for Individual Layer
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . [LAYER EDIT] button
**Switch (p. 57)
Changing the function of the pedals
. . . . . . . . . [MENU] button
2. Control FC1/FC2 Pedal Assign (p. 72)
Changing the function of the sliders
. . . . . . . . . . . . . . . . . . [MENU] button
2. Control Slider Assign (p. 73)
Changing the function of the sliders [S1] [S2] buttons
. . . . . . . . . . . . . . . . . . [MENU] button
2. Control S1/S2 Assign (p. 73)
Key Range
Setting the Key Range for each Layer
. . . . . . . . . . . . . . . . . . . . . . . . . . . .[LAYER EDIT] button
Key Range (p. 56)
Equalizer
Preventing equalizer settings from being switched
. . . . . . . . . . . . . . . . . . . . . . [MENU] button
0. System EQ Mode (p. 67)
Setting the Equalizer
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EQUALIZER knob (p. 35)
Compressor
Selecting the type of compressor
. . . . . . . . . . . . . . . . . . . . . .[MENU] button
4. Compressor Type (p. 76)
Pitch and Tuning
Changing the pitch for the entire RD-700NX
. . . . . . . . . . . . . . . . . . . [MENU] button
0. System Master Tune (p. 67)
Changing the temperament
. . . . . . . . . . . . . . . . . [MENU] button
0. System Temperament (p. 70)
Transposing the entire keyboard
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .[TRANSPOSE] button (p. 32)
Changing the pitch for each Tone
. . . . . . . . . . . . . . . . . . . . . . . . . . .[TONE EDIT] button
Coarse Tune (p. 54)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . [TONE EDIT] button
Fine Tune (p. 54)
Changing the pitch for each Layer
. . . . . . . . . . . . . . . . . . . . . . . . . . . . [LAYER EDIT] button
Transpose (p. 56)
Changing the pitch for each EXTERNAL Layer
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .[MIDI] button
Transpose (p. 62)
Changing the pitch for each key of Piano Tone
. . . . . . . . . . . . . . . . . . . . . [TONE EDIT] button
2. Micro Tune Edit (p. 48)
Reverb
Changing the amount of reverb for the entire RD-700NX
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . REVERB[DEPTH] knob (p. 33)
Changing the amount of reverb for each Tone
. . . . . . . . . . . . . . . . . . . . . . [LAYER EDIT] button
Reverb Amount (p. 56)
Changing the reverb type
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . [REVERB] button (p. 33)
. . . . . . . . . . . . . . . . . . . . . . . [MENU] button
3. Eects Rev Type (p. 74)
Chorus/Delay
Changing the amount of chorus for the entire RD-700NX
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . CHORUS/DELAY[DEPTH] knob (p. 33)
Changing the amount of chorus for each Tone
. . . . . . . . . . . . . . . . . . . . . . [LAYER EDIT] button
Chorus Amount (p. 56)
Changing the chorus type
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .[CHORUS/DELAY] button (p. 33)
. . . . . . . . . . . . . . . . . . . . . . [MENU] button
3. Eects Cho Type (p. 75)
Multi-Eects
Changing the Multi-Eects type for each Tone
. . . . . . . . . . . . . . . . . . . . . . . . . . [TONE EDIT] button
MFX1, MFX2 (p. 54)
Setting the Multi-Eects ON/OFF for Individual Parts
. . . . . . . . . . . . . . . . . . . [TONE EDIT] button
MFX1 Sw, MFX2 Sw (p. 54)
Initializing the settings
Initializing the One-Touch Piano Tone
. . . . . . . . . . . . . . . . . . . . . . . . . . . . [TONE EDIT] button
5. Initialize (p. 49)
Initializing the One-Touch E. Piano Tone
. . . . . . . . . . . . . . . . . . . . . . . . . . . . [TONE EDIT] button
2. Initialize (p. 53)
Restoring the factory settings
. . . . . . . . . . . . . . . . [MENU] button
8. Utility Factory Reset All (p. 85)
Disabling button operations
Panel Lock
. . . . . . . . . . . . . . . . . . . . . . . . . . . . [MENU] button + [ENTER] button (p. 36)

Roland RD-700NX Specifications

Power

power consumption	12 W

Audio and Sound

maximum polyphony	128 voices
sound generator	SuperNATURAL Piano, SuperNATURAL (E.Piano), Virtual Tone Wheel Organ, PCM Sound Generator, GM2 (for SMF Playback)
effects	Multi-Effects (2 x 4 systems, 84 types), Reverb (6 types), Chorus (3 types), 3-band Compressor, 4-band Digital Equalizer

Connectivity

output jacks	L/MONO, R Jacks (1/4-inch phone type), BALANCED OUT (L, R) Jacks (XLR type)
pedal jacks	DAMPER Pedal Jack, Control Pedal Jacks (FC1, FC2)
midi connectors	IN, OUT1, OUT2, THRU/OUT3

Weight and Dimensions

width	1, 444 mm (56-7/8 inches)
depth	375 mm (14-13/16 inches)
height	148 mm (5-7/8 inches)
weight	25.0 kg (55 lbs 2 oz)
