Performance
Disabling the Button
By engaging the Panel Lock function, you can disable panel functions. This prevents settings from being changed inadvertently on stage or in other
such situations.
However, you’ll still be able to operate the following buttons and knobs even while Panel Lock is in force.
• [VOLUME] slider
• [DISPLAY CONTRAST] knob
• Pitch Bend/Modulation lever
• Pedals
• ONE TOUCH PIANO buttons
• ONE TOUCH E. PIANO buttons
• [EXIT/SHIFT] button
1. While holding down the [MENU] button, and press the [ENTER] button.
A screen like the one shown at right will appear.
2. Press the ONE TOUCH PIANO buttons, the ONE TOUCH E. PIANO buttons, or the [EXIT/SHIFT]
button to cancel Panel Lock.
MEMO
You can assign the Panel Lock function to the [S1] button or [S2] button. Refer to “Assigning the [S1] [S2]
buttons When S1/S2 Mode is Set to “SYSTEM”” (p. 68).

Roland RD-700NX Specifications

Power

power consumption	12 W

Audio and Sound

maximum polyphony	128 voices
sound generator	SuperNATURAL Piano, SuperNATURAL (E.Piano), Virtual Tone Wheel Organ, PCM Sound Generator, GM2 (for SMF Playback)
effects	Multi-Effects (2 x 4 systems, 84 types), Reverb (6 types), Chorus (3 types), 3-band Compressor, 4-band Digital Equalizer

Connectivity

output jacks	L/MONO, R Jacks (1/4-inch phone type), BALANCED OUT (L, R) Jacks (XLR type)
pedal jacks	DAMPER Pedal Jack, Control Pedal Jacks (FC1, FC2)
midi connectors	IN, OUT1, OUT2, THRU/OUT3

Weight and Dimensions

width	1, 444 mm (56-7/8 inches)
depth	375 mm (14-13/16 inches)
height	148 mm (5-7/8 inches)
weight	25.0 kg (55 lbs 2 oz)
