5
Apr. 2000 VG-88
PARTS LIST
／パーツリスト
CASING /
ケース Q'ty
# 02123667 BOTTOM COVER 1
# 02123689 DISPLAY COVER 1
# 02123656 TOP COVER 1
00787756 PEDAL FV.EV-A 1
00780934 ROLAND RUBBER PLATE 1
22220321 ESCUTCHEON 222-321 7
22180605 SWITCH PEDAL 7
22355334 FOOT MKS 235-334 4
CHASSIS /
シャーシ Q't
00787767 BOLT HOLDER FV-A 2
01016212 PEDAL HOLDER 1
KNOB, BUTTON /
つまみ、ボタン Q't
# 02123690 KEYTOP UNIT 1
00341134 M R-KNOB LF BLK/BLU 1
22485303 D R-KNOB L BLK 248-303 1
SWITCH /
スイッチ Q't
# 71569134 AC SW ASSY 1
01780101 SKQKAB TACT SWITCH SW8-SW30 on 7SEG 23
13129778 SKQKAH TACT SWITCH on NUM SW1-SW7 5 +2
JACK, EXP TERMINAL /
ジャック、外部接続端子 Q't
13429825 YKF51-5054 2PZ MIDI CONNECTOR JK2 on Main 1
# 02122390 TCS5095-114152 DIN EXP CONNECTOR CN9 on Main 1
13449150 HLJ0544-01-010 6.5MM JACK JK1,JK4 on Main 2
13449155 HLJ0544-01-110 6.5MM JACK JK3,JK5-JK7 on Main 4
DISPLAY UNIT /
表示ユニット Q't
01895790 DMF-51026NY-LY LCD 1
NOTE: Replacement DMF-51026NY-LY should be made on a unit base.
注意 : DMF-51026NY-LY の交換は、ユニット単位で行って下さい。補修品は、ユニット単位。
00342445 SL-1264H LED LED9 on 7SEG 1
NOTE: Replacement SL-1264H should be made on a unit base.
注意 : SL-1264H の交換は、ユニット単位で行って下さい。補修品は、ユニット単位。
POWER SUPPLY UNIT /
電源ユニット Q't
# 71565267 PS BOARD ASSY 1
NOTE: '' includes the following parts.
注意 : 補修用 は、下記の部品を含みます。
# 02122778 HEATSINK on PS 1
# 02122789 WIRING WIRING PS CN10 on PS to CN6 on Main 1
# 02232012 SUB HEATSINK on PS 1
40011278 SCREW 3X8 BINDING TAPTITE-P FE ZC on PS 4
40011289 SCREW M3X10 BINDING P-TIGHT FE ZC on PS 1
40016590 NYLON RIVET NRP-345 BLACK on PS 2
# 40345334 HEAT-RESISTANT GLASS TUBE ESG-2 2.5FAY 1M on PS 1(5mm X 2)
PCB ASSY /
基板完成品 Q't
# 71674756 7SEG PANEL SW ASSY 1
NOTE: '7SEG PANEL SW ASSY' includes the following parts.
注意 : 補修用 7SEG PANEL SW ASSY は、下記の部品を含みます。
23503688 RIBBON CABLE 5X40-P2.0 CN7 on 7SEG to CN8 on 7SEG 1
#
∗∗∗∗∗∗∗∗
PANEL SW ASSY Assy(Unit) 1
# 02122745 WIRING OUTPUT VR CN6 on 7SEG to CN8 on Main 1
40013367 SPACER PLASTIC PIPE 3.2X5X13 on 7SEG 3
# 71674745 NUMBER BANK ASSY 1
NOTE: 'NUMBER BANK ASSY' includes the following parts.
注意 : 補修用 NUMBER BANK ASSY は、下記の部品を含みます。
40013334 SPACER PLASTIC PIPE 3.2X5X10 CLARYTY on NUM 5
#
∗∗∗∗∗∗∗∗
BANK SW ASSY Assy(Unit) 1
01568512 RIBBON CABLE 3X70-P2.0 CN2 on NUM to CN3 on NUM 1
# 71565256 EXP VR BOARD ASSY 1
NOTE: 'EXP VR BOARD ASSY' includes the following parts.
注意 : 補修用 EXP VR BOARD ASSY は、下記の部品を含みます。
# 02122801 WIRING EXP VR CN4 on EXP to CN1 on Main 1
# 71563501 MAIN BOARD ASSY (EXG) 1
NOTE: 'MAIN BOARD ASSY' includes the following parts.
注意 : 補修用 MAIN BOARD ASSY は、下記の部品を含みます。
# 02122412 WIRING LCD CN7 on Main to LCD 1
01016467 RIBBON CABLE 2X90-P2.0 CN10 on Main to CN11 on Main, 2
CN12 on Main to CN13 on Main
# 02231990 MAIN SHIELD on Main 1
# 02231989 JACK SHIELD on Main 1
# 02122401 JACK HOLDER 13P on Main 1
IC
Q't
00565123 M66310P IC (LED DRIVER) IC2 on 7SEG 1
01016434 M66312P IC (LED DRIVER) IC1 on 7SEG 1
# 02123612 UPC2933HF IC (REGULATOR) IC3 on PS 1
15199294 AN7705F IC (+5V VRGL) IC5 on PS 1
15199230 PQ05RF21 IC (V.RGL) IC5 on PS 1
# 02120867 CPU UPD703100(BP106) IC (16BIT CPU) IC1 on Main 1
00892556 TC170C140AF-003 (ESP2) IC (CUSTOM) IC12,IC13 on Main 2
# 01908412 LC22039CT-SA6 IC (I/F) IC11 on Main 1
01560289 TC55257DFL-55L(EL) IC (SRAM) IC36 on Main 1
01902212 UPD431000AGW-70LL-E2 IC (SRAM) IC2,IC4 on Main 2
01906712 LC324260AJ-60-TLM IC (DRAM) IC15,IC16 on Main 2
01898701 E28F800B5B70 IC (FLASH MEMORY) IC5 on Main 1
01780112 AK4522VF IC (AD/DA) IC23,IC30-IC32 on Main 4
15259110 TC4066BF(TP2) IC(C MOS) IC24-IC26 on Main 3
00232645 TC7W14F(TE12L) IC (CMOS) IC37 on Main 1
15259704T0 TC74HC04AF(TP2) IC (HS-CMOS) IC7 on Main 1
# 02232834 TC7SH04F(TE85L) IC (CMOS) IC6 on Main 1
00897912 TC7SH32F(TE85L) IC (2 INPUT OR GATE) IC8 on Main 1
00458034 TC75S51F TE85R IC (OP AMP) IC3 on Main 1
15289154 UPC4072G2-E1 IC (JFET OP) IC18 on Main 1
00346445 NJM2100M(TE3) IC (BIPOLAR OP AMP) IC22,IC27-IC29 on Main 4
15289109 M5216FP-600D IC (BIPOLAR OP AMP) IC19 on Main 1
15289105 UPC4570G2-E2 IC (BIPOLAR OP AMP) IC17,IC20,IC21 on Main 3
# 02122423 AN78L07M-E1 IC (REGULATOR) IC33 on Main 1
# 02124634 AN79L07M-E1 IC (REGULATOR) IC34 on Main 1
15199944 SED1335F0B IC (DRIVER) IC35 on Main 1
15289123 M51953AFP-600C IC (RESET) IC10 on Main 1
15289125 PC-410KT 178FAY IC (PHOTO COUPLER) IC9 on Main 1
!
!
!
!
E
!
!
!
SAFETY PRECAUTIONS:
The parts marked have
safety-related characteristics.
Use only listed parts oor
replacement.
安全上の注意：
が付いている部品は、安
全上特別な規格でつくられた
ものです。
交換の際は、注意をよく読み、
指定された部品番号以外の部
品は使わないようにして下さ
い。
CONSIDERATIONS ON PARTS ORDERING
When ordering any parts listed in the parts list, please specify the following items in the
order sheet.
QTY PART NUMBER DESCRIPTION MODEL NUMBER
Ex. 10 22575241 Sharp key C-20/50
15 2247017300 Knob (orange) DAC-15D
Failure to completely fill the above items with correct number and description will result in
delayed or even undelivered replacement.
パーツ発注に関するお願い
オーダーシートには、必ず下記の4 項目は正確に記入して下さい。（例外は除く）
必要数 パーツナンバー 品名 使用機種
例） 10 22575241 Sharp key C-20/50
15 2247017300 Knob (orange) DAC-15D
もし記入洩れ、誤記等が有る場合、必要部品が発送できなかったり、大幅な遅れの原因に
なります。御協力をお願いします。
The parts marked
# are new (initial
parts). *2
＃の付いた部品
は新規部品です。
7SEG PANELSW ASSY on 7SEG
NUMBER BANK ASSY on NUM
EXP VR BOARD ASSY on EXP
PS BOARD ASSY on PS
MAIN BOARD ASSY on
