7
Apr. 2000 VG-88
WIRING, CABLE /
ワイヤリング、ケーブル Q't
# 02123589 FUJI CARD 24X180-A5.0BB-P1.25-HBL8 CN4 on Main to CN5 on 7SEG 1
# 02123590 BAN CARD BNCD-P=1.25-K-14-100 CN5 on Main to CN1 on NUM 1
TRANSFORMER /
トランス Q't
# 02121189 100/120V PWR TRANS 1 +1
# 02121190 230/240V PWR TRANS 1 +1 +1
AC CORD (INSTALLED) /
電源コード（据え付け式） Q't
# 71565334 100V AC CORD ASSY 1
# 71567690 117V AC CORD ASSY 1
# 71567789 230V AC CORD ASSY 1
# 71567834 230VE AC CORD ASSY 1
# 71567889 240VA AC CORD ASSY 1
SCREW /
ねじ類 Q't
40010245 SCREW 3X6 BINDING BZC 2
40011278 SCREW 3X8 BINDING TAPTITE-P FE ZC 20
40011312 SCREW 3X8 BINDING TAPTITE P FE BZC 2
40342578 SCREW 3X6 TAPTITE S BINDING BZC 19
40019123 SCREW 3X8 BINDING TAPTITE S BZC 14
40012512 SCREW 3X6 BINDING TAPTITE S ZC 9
40015945 SCREW 3X8 BINDING TAPTITE S FE ZC 5
40013001 SCREW 4X8 PAN W SEMS BZC 4
40123545 JACK NUT 9X11X2 HLJ0999-01-240 FE NI 6
40011745 HEX NUT M4 SPRING NUT FE ZC 3
40011856 INSULATING WASHER 3X8X0.8 FIBER-W 1
40016467 JACK WASHER M9.2X14X0.5 FENI 12
40011923 WASHER M9.1X13 INTERNAL TOOTH 1
40015989 HEX BOLT 6X67 HALF THREAD BZC 1
40016001 LOCK NUT M6 U BZC 1
40016067 PLAIN WASHER 6X13X1 BZC 2
40015901 E-RING M2.5 SUS 1
PACKING /
梱包材 Q't
# 02232801 CARTON PAD 1
# 02232812 PAD B 2
# 02232823 PAD C 1
# 02232790 CORNER PAD 4
# 02123501 PACKING CASE 1 +1
MISCELLANEOUS /
その他 Q't
12569249 LITHIUM BATTERY CR2032 220MAH/3V 1
22350312 BASE 6
00568945 PEDAL LABEL(BANK DOWN) 1
# 02122689 PEDAL LABEL (CTL) 1
# 02122656 PEDAL LABEL (2) 1
# 02122645 PEDAL LABEL (1) 1
# 02122678 PEDAL LABEL (4) 1
00568956 PEDAL LABEL(BANK UP) 1
# 02122667 PEDAL LABEL (3) 1
# 02123678 INSULATING SHEET 2
01016267 SHAFT STAY 1
40017356 COATING CLIP CS-4 1
40347934 SILICON GREASE KS-64 100G 1
40016378 TRMINAL TER61-0171 TER1-TER7 on PS 7
12189815 BATTERY HOLDER BH-32 BT1 on Main 1
01120978 CUSHION 30X10X2 1
01016223 FOOT 30X10X3 1
22140315 HOLDER PIN PIN 214-315(FOR FV/EV) 1
22350171 RUBBER FOOT 235-171 7
22170103 SUPPORT SPRING (FOR SWITCH PEDAL) 7
40126812 CAUTION LABEL BARRIER(100V/117V ONLY) 1
40122645 NITTO FILAMENT TAPE #2883 W19MM 50M 60P (CM)
40122556 DOUBL FACED ADHESHIVE TAPE #575X W30MM 30M 10P 30CM
40235189 RING SE-9
ACCESSORIES (STANDARD) /
標準付属品 Q't
00349067 ORIGINAL CNECT CORD C-13A 1 +1
# 71565301 OWNER'S MANUAL JAPANESE 1
# 71567667 OWNER'S MANUAL ENGLISH 1
40232334
保証書セット（持込み修理用）
JAPAN ONLY 1
IDENTIFYING THE VERSION NUMBER
／バージョンナンバーの確認方法
!
!
!
!
!
!
!
1. Turn the power off.
2. While pressing [CURSOR(DOWN)] and [COSM AMP] key,
turn on power.
3. The version number is displayed.
1．電源をオフにします。
2．[CURSOR(DOWN)] と [COSM AMP] を押しながら電源をオ
ンします。
