5 x Control unit operation
42
FA ROTEX Solaris - 08/2007
5.3 Adjustments and menu guidance
Table 5.1 gives an overview of the available measurement points and the associated display formats. Table 5.2 shows a summary
of the displays for the calculated parameters.
Tab. 5-1 Overview of measurement points
Tab. 5-2 Maximum values and calculated values
5.3.1 Display during start-up
After switch-on, the Solaris R3 control unit goes through a self-testing routine, during which all the display elements and the
adjustment parameters are shown separately. The following testing steps are carried out and the results are displayed for about
2 seconds (Fig. 5-4):
– Immediately after switch-on, the start-up display shows the installed software version and the controller's serial number.
– During first commissioning, the display then shows the language selection page.
– For safety reasons, the functions of the pumps and their operating condition lights can only be checked manually
(see section 5.2.5).
Measurement Name Measuring range Resolution Sensor
Display
t
K
Solar panel temperature –30 to 250°C 1 K Pt 1000 temperature sensor
t
R
Return flow temperature 0 to 100°C 1 K PTC temperature sensor
t
S
Storage tank temperature 0 to 100°C 1 K PTC temperature sensor
t
V
feed temperature 0 to 100°C 1 K FlowSensor with 0.5–3.5 V output signal
V Flow 0.0 to 20.0 l/min 0.1 l/min FlowSensor with 0.5–3.5 V output signal
Parameter Name Value range Resolution Remark
TK max
Max. measured solar panel
temperature
–30 to 250°C 1 K none
TK min
Min. measured solar panel
temperature
–30 to 250°C 1 K none
V max Maximum flow 0.0 to 20.0 l/min 0.1 l/min Maximum flow measured during filling
PS Peak output 0.0 and 99.9 kW 0.1 kW
Maximum mean value determined
during 5 minutes
PS (15h) Peak value of the day 0.0 and 99.9 kW 0.1 kW
Maximum peak value during the
last 15 hours
W (15h) Heat yield of the day 0.0 and 999.9 kW 0.1 kWh
Heat yield calculated from
instantaneous output during the
last 15 hours
w Total heat yield
0.0 to 9999.9 kW
or 10,000 to
99,999 kW
0.1 kWh
0.0001 MWh
Total solar heat yield calculated from
instantaneous output
P Instantaneous output 0.0 and 99.9 kW 0.1 kW Mean value during the last minute
DT
Set-value for temperature
difference
1 to 15 K 1 K
Set-value for temperature difference
T
V
–T
R
during modulated operation
P1 Present output stage of P1 0 to 100 1% none
Min. stage
Smallest enabled output
stage of P1
0 to 10
0 to 100
1; 1%
Only accessible for an expert
(see Fig. 5-6)
Stage "On"
Runtime of circulation
pump P1
0 to 99999h 1h
Only accessible for an expert
(see Fig. 5-6)
